X670E GAMING PLUS WIFI

• Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors
  Socket AM5
• 4x DDR5 UDIMM, Maximum Memory Capacity 256GB
  Memory Support DDR5 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MT/s
  Max. overclocking frequency:
  • 1DPC 1R Max speed up to 7800+ MHz
  • 1DPC 2R Max speed up to 6400+ MHz
  • 2DPC 1R Max speed up to 6400+ MHz
  • 2DPC 2R Max speed up to 5400+ MHzSupports Dual-Channel mode
  Supports non-ECC, un-buffered memory
  Supports AMD EXPO™
• 1x HDMI™
  Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
  1x DisplayPort
  Support DP 1.4, maximum resolution of 4K 60Hz**Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
• Slot 3x PCI-E x16 slot
  Supports x16/x1/x4
  • Supports x16/x1/x4 (For Ryzen™ 9000/ 7000 Series processors)
  • Supports x8/x1/x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
  • Supports x4/x1/x4 (For Ryzen™ 8500/ 8300 Series processors)
  1x PCI-E x1 slot
  PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
  PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
  PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
  PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset
